Maximum module voltage: 62V.
2 to 15 cells in series with a maximum voltage of 4.2V per cell.
3 to 16 cells in series LFP (LiFePO4).
Charging current: up to 80A.
Recuperative discharge current: up to 90A (during discharge, energy is returned to the grid).
Built-in resistive load with a current of up to 120A for quick testing of connection quality
between cells and measuring the internal resistance of cells.
16-channel balancer that can operate in both charge and discharge modes, with a current of
up to 2A.
Supports 48V batteries from mild hybrids controlled via CAN bus.
Supports BMS with RS485 bus.
Universal and specialized cables for easy connection of battery modules.
Reverse polarity protection.
Cell temperature monitoring.
Testing scenarios, user-configurable test parameters.
Remote control via LAN.
